Chief Architect X10 Reference Manual

• Click the Delete button to remove the tation Set is made active. This option is
selected saved default from the list of the default for installed Annotation Sets.
those available in the plan or layout. • Click the Define button to open the Layer
• Select a Layer Set from the drop-down Display Options dialog. Not available
list. See “Layer Sets” on page 187. when “Use Active Layer Set” is selected.
• When “Use Active Layer Set” is selected, See “Layer Display Options Dialog” on
the layer set in use in the current view page 190.
does not change when the Selected Anno-

Exporting and Importing Annotation Sets
Annotation Sets can be exported • All Layer Sets that are associated with an
out of a plan or layout file and Annotation Set. Layer Sets not associated
then imported into other plans or layouts. with an Annotation Set are not exported.
When you export Annotation Sets, all of the
Multiple Saved Defaults in the file are Import Annotation Sets Dialog
exported, regardless of whether they are used To import Annotation Sets into a plan
by an Annotation Set. See “Multiple Saved or layout, open that file and then select
Defaults” on page 89. File> Import> Import Annotation Sets.
After you select a file to import, the Import
Exporting Annotation Sets Annotation Sets dialog opens.
To export a plan or layout’s
Annotation Sets, open that file and
then select File> Export> Export
Annotation Sets. The Export Annotation
Sets dialog is a typical Save As dialog that
lets you specify the exported file’s name and
its saved location on your computer. See
“Exporting Files” on page 60.
Exported Annotation Sets files use the
.cadefs file format. Information exported in
.cadefs files includes:
• All Annotation Sets saved in the current
file.
• All Saved Defaults for Manual Dimen- 1 The current File pathname displays
here. Click the Browse button and
sions, Text, Rich Text, Callouts, Markers, browse to the location of a different .cadefs
and Arrows. file you wish to import. If the pathname is
