Chief Architect X10 Reference Manual

1 Annotation Sets - 2 The Current Active Defaults for each
of the annotation object types.display
• The Annotation Set that you are Cur- and can be changed here.
rently Using is selected in the drop-down • Select a Saved Default from the drop-
list. If “Active Defaults” is selected, the down list associated with any of the anno-
Current Active Defaults, below, are not tation object types.
associated with a saved Annotation Set. • Click the Add button beside any Saved
• Select a different Annotation Set from the Default to create a new Saved Default for
drop-down list to activate it when you the object type based on the one that is
click OK. currently selected. Type a short, descrip-
• Click the Define button to open the tive name for the new Saved Default, then
Annotation Sets dialog. See “Annotation modify its settings as needed.
Sets Dialog” on page 94. • Click the Edit button to open the defaults
• When “Active Defaults” is selected, you dialog for the object type and make any
can click the Save Current Active changes you may need to the selected
Defaults button to create a new Annota- Saved Default.
tion Set based on the current Active • Click the Delete button to remove the
Defaults. selected Saved Default from the list of
those available in the plan or layout. Note
that if a Saved Default is either in use or

92
