Annotation Sets

1 A list of the Annotation Sets available • The name of the Selected Annotation Set
in the current plan or layout display displays here. You can change the
here. selected set’s name by typing in the text
• Click on an item in the list to select it. field. Names are case-insensitive and
must be unique.
• The selected set is highlighted and dis-
plays in the Name field to the right. • Select the Current CAD Layer from the
drop-down list or click the Define button
• When a set is selected, its name and other to open the Layer Display Options dia-
attributes can be edited. log. See “Current CAD Layer” on page
• Click the New button below the list to a 292.
new Annotation Set. Type a short, • For each annotation object type, select a
descriptive name for the new set in the Saved Default from the drop-down list.
Name field to the right.
• Click the Add button to create a new
• Click the Copy button below the list to Saved Default for the object type based
create a copy of the Annotation Set. Type on the currently selected Saved Default.
a short, descriptive name for the new set Type a short, descriptive name for the
in the Name field to the right. new Saved Default, then modify its set-
• Click the Delete button to delete the tings as needed.
selected Annotation Set from the list. • Click the Edit button to open the defaults

2 Information about the Selected dialog for the object type and make any
Annotation Set displays and can be changes you may need to the selected
modified here. Saved Default.

95
