Cylinder Specification Dialog

3 A preview of the sphere displays on the Line Style Panel
right side of the dialog box. See
“Dialog Preview Panes” on page 42. For information about the settings on this
panel, see “Line Style Panel” on page 301.
Shape Panel
Materials Panel
For information about the settings on this
panel, see “Shape Panel” on page 989. For information about the settings on this
panel, see “Materials Panel” on page 1017.

Cylinder Specification Dialog

Select a cylinder and click the Open
Object edit button to open the
Cylinder Specification dialog.

1 Specify the Center Point of the 3 The Rotation settings allow you to
selected cylinder’s base in relation to rotate the selected cylinder about the X,
the origin point of your plan. See “Entering Y, and Z axes. See “3D Drafting” on page 32.
Coordinates” on page 174. • Select the X, Y, or Z Axis as the axis
• Enter the X, Y, and Z Position coordi- around which the cylinder will rotate.
nates of the cylinder’s center point. • Specify the Angle to rotate the cylinder
2 Size - Specify the Radius and Height in the text field. The default value is 90°.
of the selected cylinder. • Click the Rotate + button to rotate the
cylinder around the selected axis in a
clockwise direction.

985
