Polyline Solid Specification Dialog

General Panel

• Check Hole in Polyline Solid to convert Polyline Panel
the polyline solid into a hole in a sur-
rounding polyline solid. The POLYLINE panel states the length of the
polyline solid’s Perimeter, its enclosed
• Specify the Thickness of the polyline Area, and its Volume. See “Polyline Panel”
solid. Increasing the thickness will cause on page 314.
the polyline solid to grow upward (hori-
zontal) or toward the elevation/cross sec- If the selected polyline solid has any Holes in
tion camera (vertical). it, they will be subtracted from the Area and
Volume values. See “Holes in Polyline
The settings that follow are only available for Solids” on page 990.
polyline solids drawn in floor plan view.
• Select the Elevation Reference, which is Selected Line/Arc Panel
where the Floor to Top and Floor to Bot-
tom are measured from. The selection The SELECTED LINE panel is available when
here will influence the labels of these two the selected edge is a line as opposed to an
settings, below. arc. See “Line Panel” on page 300.
• Specify the polyline solid Top height, The SELECTED ARC panel is available when
which is measured from the Elevation the selected edge has been convered into an
Reference selected above. The label for arc. See “Arc Panel” on page 309.
this setting will vary depending on which
Elevation Reference is selected. Line Style Panel
• Specify the polyline solid’s Bottom For information about the settings on this
height, which is the height of its bottom panel, see “Line Style Panel” on page 301.
surface, measured from the Elevation
Reference. Fill Style Panel

For information about the settings on this
panel, see “Fill Style Panel” on page 315.

991
