INSTALLATION & STARTUP
Chapter 16 Dryers
Side Kick® Dryer Option
Overview
The Side Kick® nozzle is a dryer add on which increases drying performance when used in conjunction with the
onboard dryer. The Saber® homes at the exit end of the wash bay which allows the carriage to double as a stationary
dryer after the wash cycle is complete. The advantage to this set up is it eliminates the need for a separate frame
structure and also offers a couple of options and sell ups for wash packages.
The Side Kick® nozzle mounts to both a wall mount frame a well as a floor mount frame but for each application uses
a different mounting bracket. The next steps will describe mounting both the wall and floor mount side nozzles.
Specifications
Building Requirements
Height Standard Saber® Height: 130”
Width Minimum 14’ – 8” (174”)
Length Standard Saber® Length from Exit Wall (minimum): 37”
Electrical Requirements
208 / 230 / 460 VAC
