18V 3/4“ IMPACT WRENCH

High quality, heavy duty 3/4" Impact Wrench delivering a
class-leading 711Nm of torque.

Strong internal impacting mechanism.
The powerful impact mechanism provides over 711Nm of torque for heavy
duty applications.

Excellent power-to-weight ratio.
The Master 18V 3/4“ Impact Wrench is one of the most powerful impact
guns on the market and weighs only 3.1 kgs.

Sleek and ergonomic design.
The Master 18V 3/4“ Impact Wrench has an innovative ergonomic design
that looks both sleek and professional.

Square drive with friction ring.
The 3/4” square drive anvil with friction ring allows the user to make quick
and easy one-handed socket changes whilst on the job.

Variable speed trigger.
Description Art. No. Pack Qty.
18V 3/4" Impact Wrench* 0700 735 09 1 The variable speed trigger allows the tool to run from 0 - 1,900 RPM
*Battery not included. providing enhanced user control.
Technical Data Enhanced runtime.
Voltage 18V The tailored Lithium-ion cells provide up to 30% more runtime per charge
Torque 711Nm than competitors models.
Revolutions per minute 0 - 1,900 RPM
Impacts per minute 0 - 2,200 IPM No cords or airlines.
Length 230 mm This allows ease of operation and exibility as well as the convenience to
Weight (with battery) 3.1 kg use the tool anytime and anywhere.
Anvil size 3/4" square drive
Anvil type Friction Ring Strong and robust housing.
Power gauge Yes - on battery The aster 1 3 Impact Wrench is extremely tough and has a robust
Battery type Lithium-ion three component, shock resistant casing.
Charge time 1 hour
Warranty 2 years 2-year warranty.

AUS. pub. 04/16 © Partner Products:
18V Li-Ion Batteries
Tool Bag
Personal Protective Equipment
