Body - Inner and outer trims BW - 65

d. Remove the front door inner armrest mounting bolts and IN
remove the front door inner armrest.
DI

EG

TR

4. Remove the front door inner guard armrest shell
AX
a. Remove the front door inner guard armrest shell

mounting screw.
FR
b. Remove the front door inner guard armrest shell with the

pry lever.
ST

BR

5. Remove the front door inner guard assembly
BW
a. Remove the front door inner guard mounting buckle with

the inner trim pry lever.
EL
Caution

● Observe the distribution of the door guard mounting
buckles, insert the pry level into each buckle position as
possible, to remove them one by one.
● Do not use the removed buckles again.

b. Remove the front door inner guard assembly.

6. Install front door inner guard assembly

a. Install the front door inner guard mounting buckles.

Caution

The front door inner guard mounting buckles are

disposible parts, and should be replaced with new parts
for installation.

BW-065
