Electrical system – electrical components EL - 55
IN
Scrubber
Change DI
1. Disconnect the cable of battery negative pole
2. Open the front flip-over cover assembly EG
3. Remove the washer dispenser
a. Disconnect the scrubber connector TR
b. Disconnect the washing water hose
Caution AX
Collect the outflowed liquid.
FR
ST
c. Pull out the washer dispenser.
BR
BW
EL
4. Check washer dispenser motor if following failures are present. If yes, repair or replace the washer
dispenser motor.
a. Shortcircuit occurs inside the washer dispenser motor.
b. Poor electrical conductivity of the internal contact of the washer dispenser motor exists.
c. Abnormal sound can heard form inside the washer dispenser motor.
5. Installing the washer dispenser
a. Install the washer dispenser on to the windshield washer
tank.
EL-055
