EL - 54 Electrical system – electrical components
IN
Windshield wiper
DI Change
1. Removing the left windshield wiper
EG a. Lift the left windshield wipers from the windshield.
b. Press the fixing clip of the left windshield wiper. Remove
TR the windshield wiper.
AX
FR
2. Removing the right windshield wiper
Pay attentions to
ST
Remove the right windshield wiper in the same way as removal of the left windshield wiper.
3. Check the windshield wiper if the wiper blade is broken or detached and so on. Replace
BR
the windshield wiper if necessary.
BW 4. Installing the left windshield wiper
a. Put the windshield wiper into the correct place.
EL b. Install the left windshield wiper onto
the windshield wiper bracket fixing clip.
Caution
When hearing click sound, it means that
left windshield wiper is fitted on the correct place.
5. Install the right windshield wiper
Caution
Install the right windshield wiper in the same way as installation of the left windshield wiper.
EL-054
