Electrical system – electrical components EL - 49
IN
5. Installing the windshield wiper electric motor
assembly DI
a. Mount the windshield wiper motor into place.
b. Mount and tighten the fixing bolts for EG
the windshield wiper motor.
TR
AX
c. Connect the ball joint between the windshield wiper
electric motor assembly and the windshield wiper linkage
FR
mechanism assembly.
Caution
ST
Apply lubricating grease onto the mounting place of the
ball joint.
BR
BW
d. Connect the plug & socket connector of
the windshield wiper electric motor assembly.
EL
6. Connect the cable of battery negative pole
7. Close the front flip-over cover assembly
8. Check if the wiper leaf assembly can be back automatically
EL-049
