Electrical system – electrical components EL - 47

IN

c. Put the left wiper arm and blade assembly into the correct
place. DI
d. Mount and tighten the fixing nut for the wiper arm.

Caution EG

● The left wiper arm and blade assembly shall be at the
lower edge of the windshield assembly. TR

● Lift left wiper arm up and put it into the correct place.
AX

e. Engage the cover of the wiper blade assembly nuts.
Caution FR

● Put down left wiper arm onto the windshield after
installation. ST
● Confirm that the windshield wiper is at the lower edge
of the windshield.
BR
f. Connect the washer hose.

BW
5. Check if the wiper leaf assembly can be back automatically

a. Put the wiper arm and blade assembly switch in to INT/LO/HI position, to swing the wiper arm and blade
EL
assembly.

Caution

Never switch on the wiper arm and blade assembly switch when the windshield is dry, to avoid

scratching the windshield.

b. Switch off the wiper arm and blade assembly switch in to “OFF” position to make the wiper arm and blade

assembly return to its original place.

c. Check if the windshield wiper at lower edge of the windshield assembly.

6. Install the right wiper arm and blade assembly

Caution

Install the right wiper arm and blade assembly in the same way as installation of the left wiper arm and

blade assembly.

EL-047
