EL - 72 Electrical system – electrical components
IN
Horn
DI Change
1. Switch off the ignition switch Set the transmission at neutral and start the parking brake
EG 2. Disconnect the cable of battery negative pole
3. Removing the horn
TR a. Disconnect the plug & socket connector of the horn.
AX
FR
ST
b. Remove the fixing nut from the horn. Remove the horn.
BR
BW
EL
4. Check the horn if following failures are present. Replace the horn if necessary.
a. The horn body is broken.
b. Shortcircuit occurs inside the horn.
c. The horn body failed.
5. Installing the horn
a. Install the horn into place. Tighten the horn fixing nut.
EL-072
