EL - 246 Electrical system –circuit
IN
DI
EG
TR
1-1813099-2 AMP LA406-H FD
AX
F017 Left front wheel solenoid valve F019 To Intake air preheater
FR Terminal number Color Function Terminal number Color Function
Left front wheel solenoid 1 Red - Blue Power supply, preheater
1 Blue - white
valve power supply
ST
Earth, left front wheel
2 White - black
solenoid valve
BR
Left front wheel solenoid
3 Red - Yellow
valve signal
BW
4 - -
EL
441 032 809 0 WABCO
F020 Left front wheel speed sensor
Terminal number Color Function
Left front wheel speed sensor
1 Brown
power supply
1-1813099-2 AMP
2 Black Left front wheel speed sensor
F018 Right front wheel solenoid valve
Terminal number Color Function
Right front wheel solenoid
1 Blue - red
valve power supply
Earth, right front wheel
2 White - black
solenoid valve
Right front wheel solenoid
3 Green - red
valve signal
4 - -
EL-246
