EG - 22 Engine section – Engine (Cummins ISF3.8)

Failure phenomenon Possible reason Failure elimination

Check the battery or the power circuit of switch-free
Battery voltage low
battery

Check the battery cable and connection. Clean or eeplace
Battery cable loose, broken or corroded
the cable if necessary

Battery capacity lower than specification Check the battery. Repair or replace it if necessary

Battery cable diameter or length not Use a piece of cable with a larger diameter or shorter
correct length to replace the battery cable

Engine oil pressure switch, pressure
Check if the engine oil pressure switch, pressure gauge,
gauge or sensor failed or installation
pressure sensor work well and the positions are correct
position not correct

Engine drive device meshed Disengage the engine driving device
The engine fails to
Starter circuit part failed Check the starter circuit parts
drag or drag slowly
Starter motor pinion or gear ring broken Dismount the starter motor and check the gear

Check the engine oil level. Verify if the engine oil scale
Engine oil level higher than specification
calibration and oil sump capacity is correct

Engine oil not meeting the specification
Replace the engine oil or filter
of working condition

Check if the crankshaft rotates flexibly. If necessary,
Crankshaft rotation not smooth
repair or replace relevant parts

Dismount the injector and rotate the crankshaft Check the
Cylinder hydraulic block
source of liquid in the cylinder
Separate the engine oil and check the filter to determine
Engine broken internally
the possible broken part

Do not stop the Key switch circuit failure Check the key switch circuit
engine The electric control module (ECM) fails Replace ECM

Key switch at off (open) Turn the key switch to ON

Check if the warning indicator has voltage If necessary,
Error code warning indicator burnt
replace the bulb
Error code warning
indicator not on
Error code warning indicator circuit
Check the error code warning indicator circuit
failure
Key switch circuit failure Check the key switch circuit

EG-022
