Engine section – Engine (Cummins ISF3.8) EG - 207

Air filter IN
Clean

1. Check the dust bag of air filter DI

a. Squeeze the head of dust bag of air filter by hand to see if
there is dust blowing out, if the dust blows out, check and EG
clean it.
TR

AX

2. Clean the air filter FR

a. Open the air filter cover, remove the inside and outside
filter element of air filter. ST

BR

BW

b. Clean if the dust inside of the air filter and that on the cover surface is wiped up. EL
c. Clean the air cleaner element.
Caution

Filter element shall be cleaned regularly, and do not use compressed air to clean from the outside of the
filter element, thus the dust will gets into the filter element. Rotate the filter element with compressed
2
air (7kg / cm below) by hand while blowing dust away from the inner surface of the filter element.

EG-207
