Engine section – Engine (Cummins ISF3.8) EG - 205
change IN
1. Park the car on a smooth road, stop the engine after parking, place the transmission in neutral, and
enable the parking brake DI
2. Remove the high intake pipe assembly
a. Remove the bellows fixing collar and remove the bellows EG
assembly.
Caution TR
Turn the cab slightly forward for easy removal and
installation of the high intake pipe assembly. AX
FR
b. Remove the fixed bolts and nuts of high intake pipe and
remove the high intake pipe assembly. ST
BR
BW
EL
3. Install the high intake pipe assembly
a. Install the high intake pipe to the installation position,
attach the fixed bolts and nuts and tighten them.
Torque: 41~51N•m
EG-205
