VEHICLE MAINTENNANCE - REPLACEMENT 05-53

(b) Install the small baffles on both sides and
tighten the retaining bolts.

05

9 . Lower the vehicle.
10 . Top up the engine coolant to the specified
level.
Volume: 9L

NOTICE

• Specification: glycol 50/50
• Normal temperature area: -25#
• Winter (Beijing): -35#
• Winter alpine region (-30 degree): -45#

11 . Tighten the coolant filler cap.
NOTICE

• Remember to turn the free point on the
inlet cap to that between the two free
points on the inlet.

12 . Start the engine and accelerate to 2500 r/min, until the electronic fan runs quickly.
Check whether the coolant in the coolant reservoir reaches the specified level.
If not, continue to top it up to the specified level.
