05-54 VEHICLE MAINTENNANCE - REPLACEMENT

REPLACE ENGINE OIL

NOTICE

• In general, the oil filter shall be replaced along with the engine oil, or it may
contaminate the new oil and affect the engine functioning.

1 . Place the vehicle on a level ground.
2 . Heat up the engine to its normal working temperature.
05
3 . Switch off the ignition.
4 . Wait for around 3 minutes.

5 . Screw out the engine oil filler cap, pry out
engine trim cover.

6 . Slowly pull out the oil gauge.

7 . Check the quality of the engine oil. If it is too dirty or thin, fix the fault and then
replace the oil.
