83-16 INSTRUMENT PANEL - DASHBOARD

(l) Install the fastening screw at the instrument
panel trim strip.

ftwx831069

(m) Install the instrument panel trim strip.

83

ftwx831068

17 . Refit the dashboard lower body assembly.
(a) Refit the dashboard lower body.
NOTICE

Adjust the lower rail of the instrument panel
carefully and make sure it is fitted in place.

(b) Reconnect the cigarette lighter connector,
USB/AUX connector and onboard power
supply connector.

ftwx831048
