MECHANICAL REMOTE CONTROLS

SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL REMOTE CONTROL ADAPTER HARNESS MECHANICAL REMOTE CONTROLS

881170A15 84-892473A01
This control features a handle mounted power trim switch, 15 ft. Converts the traditional Mercury connector to an Amp 8‑pin connector.
(4.58 m) harness, built‑in warning horn and power trim leads for front mount Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series ignition
switch. keyswitch harness to connect to the MY2005 and newer 8/9.9 hp. FourStroke
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and outboard.
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an (351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
adapter harness is required.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used. HARNESS EXTENSION- 10 PIN
GEN I cables must be used.
881170A20
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness,
built‑in warning horn and includes power trim leads for front mount switch.
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power
trim). When used with MY2005 and newer 8/9.9, 15/20 FourStroke outboards an
adapter harness is required.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN I cables must be used.
SIDE MOUNT REMOTE CONTROL- 10 PIN AMP
84-8M0058668
This harness extension will allow you to increase the length by 6 feet of the 10 pin
drop for instruments. The extension will work with Side Mount controls as well as
any 896537 series main engine / boat harness.

881170A10
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness
with Amp 10‑pin connector. The control will connect to the engine models below
without the use of an adapter.
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN I cables must be used on other engines.
SIDE MOUNT REMOTE CONTROL
881170A11
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness
with Amp 10‑pin connector. The control will connect to the engine models below
without the use of an adapter harness.
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN I cables must be used on other engines.
