MECHANICAL REMOTE CONTROLS SIDE MOUNT REMOTE CONTROL- 14 PIN

MECHANICAL REMOTE CONTROLS MSC 4000 SIDE MOUNT - ELECT, NON-POWER

TRIM

The 8M0083860 is not "push to choke" and has a 14 pin connector
wiring harness, lanyard stop, throttle only feature. This control also
requires Gen II throttle and shift cables, is starboard mounted and not
stackable.
The remainder of controls 881170A3, 881170A5, 881170A7, 881170A12
can be mounted starboard or port side and are stackable. They offer
"push to choke" ignition switch, 8 pin connector wiring harness, lanyard
stop switch, separate neutral warm‑up lever and requires Gen I throttle
and shift cables. All controls have a 5 pin accessory plug for tachometer
and an adjustable throttle friction. These controls are not for use with 881170A16
engines that have counter rotating lower units. Older engines may For non‑power trim models, 15 ft.(4.58 m) harness and built‑in warning horn. New
require an adapter harness. design with soft grip. Ref. Throttle/shift cable Gen I ‑ 897977A__. Throttle/Shift
cables (896143A) for MY2005 and newer 8/9.9 FourStroke outboards. 8‑9.9 4
SIDE MOUNT REMOTE CONTROL- 14 PIN Stroke engines generation change above S/N OR192772 and new 15/20 4 Stroke
engines will use Gen I series T/S Cables
Fits all current Mercury/Mariner outboards 6 hp. and above (without power trim),
and 1993 and newer Force outboards 40 hp and higher utilizing Mercury style
cables (with power trim). When used with a MY2005 and newer 8/9.9/15/20
FourStroke outboard an adapter harness 892473A01 is required. Gen I cable must
be used with this control
SIDE MOUNT REMOTE CONTROL

8M0138642
This control features non ‑ power trim and a 15ft. (4.58m) harness with 14 pin
Deutsch connector.
Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim),
and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury cables
(without power trim).
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
Adapter harness is required. 2 pin connector is now included to allow for use of 881170A 3
SmartCraft accessories with analog gauges. This control features a non‑power trim handle, 15 ft.(4.58 m) harness and built‑in
Gen II cable must be used. warning horn.
SIDE MOUNT REMOTE CONTROL Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim)
8M0103451 and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury style
cables (with power trim).
This control features a non ‑ trim handle and a 15 ft. (4.58 M) harness with Amp For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
connector and will direct connect to the engine models below without the use of an used.
Adapter harness. For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
For MY2005 and newer, 8/9.9, 15/20 HP FourStroke Outboards with electric start FourStroke engines will use GEN I cables.
and non‑trim. When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be Adapter harness is required.
used. GEN I cables must be used on other engines.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20 881170A 5
FourStroke engines will use GEN I cables.
GEN II cables must be used on other engines. This control features a non ‑ powered trim handle with a 15 ft.(4.58 m) harness.
This control does not have a warning horn and features push throttle cable
8M0103454 operation.
This control features a non‑power trim handle, 15 ft.(4.58 m) harness and built‑in Fits Mercury/Mariner Outboards 20/25 HP (U.S. S/N 0G044026 and below;
warning horn. Belgium S/N 9807908 and below).
Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim) GEN I cables must be used.
and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury style
cables (with power trim).
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
used.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
Adapter harness is required.
GEN II cables must be used on other engines.

486 2019 Quicksilver Precision Parts & Accessories Guide
