Page 548 - Quicksilver Accesories Guide 2019

DIESEL RIGGING

CCM MODULE AXIUS GEN II VESSEL SENSOR HARNESS DIESEL RIGGING

77-8M0075769 84-879312T13
CCM Module with Software (CCM10) Vessel sensor harness with neutral safety.
QSD Axius Gen II SC 2.5 (CCM 10) Twin Engines
EXTENSION HARNESS- NEUTRAL SAFETY
CCM MODULE SC 2.2 PORT

84-899887T01
77-8M0075794 Harness extension used with neutral safety switch. (DTS Shift Actuator)
CCM Module with Software (CCM 48) Sterndrives (DTS)
QSD Axius Gen I ‑ CCM Module SC 2.2
GEAR ACTUATOR HARNESS
CCM MODULE SC 2.2
77-8M0075795
CCM Module with Software (CCM 48)
QSB, QSC, QSM, QSD Inboards and Sterndrives ‑ CCM Module SC 2.2
ADAPTERS AND HARNESSES

SHIFT ACTUATOR HARNESS

84-879312T10
Gear actuator harness.
On/Off
Forward/Reverse.
Inboard with DIN connector.
GEAR ACTUATOR EXTENSION HARNESS

84-879312T12
Shift actuation harness.
Sterndrive harness extension

84-879312T11
Actuator extension harness DTS Troll with DIN Connector
Gear On/Off, Forward/Reverse
Twin Disc gear actuation

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 541
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
