4 POSITION TRIM SWITCH ADAPTER ZERO EFFORT TRIM ADAPTER HARNESS

84-896394T01 84-8M0109408
Used with all dash mounted triple and quad trim switches to adapt to Zero Effort Included in Race Rigging Kits.
Controls Required for any newer style Zero Effort control with 8 pin Trim All connector.
Triple/Quad engines Harness is 8 pin Zero Effort to bullet connectors
2006 / 2007 (Gen II) DTS engines
DUAL ENGINE ZERO EFFORT 8 PIN TRIM ALL
TRIPLE ENGINE TRIM HARNESS KIT-DTS HARNESS

84-895744A02 84-8M0047784
Allows connection of multiple DTS engines to trim switches (triple engine with Zero Harness that provides individual bullet drops for rocker switches from the 8 pin
Effort Controls‑included in kit) Trim All connector on the newer Zero Effort remote controls
QUAD ENGINE TRIM HARNESS KIT-DTS Connects a dual engine Zero Effort control with the newer 8 pin Trim All connector
to individual rocker switches via bullets
TRIM LIMIT KITS

Trim limit kits available to adjust trim up limits
TRIM LIMIT SWITCH KIT

84-895744A04 ELECTRICAL
Allows connection of multiple DTS engines to trim switches (Quad engines with
Zero Effort Controls‑included in kit)
ENGINE TRIM HARNESS KIT-DTS
84-8M0072808
Allows connection of multiple DTS engines to trim switches (Quint engines with
Zero Effort Controls‑included in kit)) 899625K02
2005 Verado, 200/225 OptiMax DTS and DTS 8.1L / 496 Mag MCM/MIE engines
Limits the up travel of the power trim to minimize potential interferences when fully
tilted. This is an analog device.
Fits the Mercury/Mariner Opti Max 1.5L (75‑115), 2.5L (135,150,175 and 3.0L
(200‑300) Can also be used in 75‑115 4 stroke engines (Serial number
1B366823‑2B094955.)
