Page 622 - Quicksilver Accesories Guide 2019

ELECTRICAL

TRANSOM MOUNTED POWER TILT PANEL POWER TRIM SWITCH KIT

87-815200A02 87- 18286A18
Rocker switch style with 6 ft.(1.8 m) harness and bullet connectors. Provides tilt Rocker style switch with 10 ft. harness and bullet connectors. Can be surface
control from the outside of the boat when trailering and launching. "T" harness mounted or flush mounted. Provides tilt control from the bow or transom location.
(included in kit) connects directly to trim pump with 3 pin Packard connector. Fits Mercury/Mariner models equipped with integral trim pump.
Fits MCM models with newer power trim having the 3 pin Packard connector.
POWER TRIM SWITCH KIT
OUTBOARD POWER TRIM SWITCH KITS

POWER TRIM SWITCH KIT

87- 18286A46
Rocker switch style with 25 ft.(7.62 m) harness and bullet connectors. Can be
surface mounted or flush mounted. Provides tilt control from the bow or transom
location.
87- 14645A 4 Fits Mercury/Mariner 75‑115 hp. FourStroke outboards beginning with serial
Toggle switch style. Tiller handle mounted. number 1B366823‑2B094955.
Fits Mercury/Mariner 40 JET and 50/60 hp. outboards and operates the power trim POWER TRIM SWITCH KIT
kit added to a base ELHO model engine. See Tiller application chart for specific
engine models.
POWER TRIM SWITCH KIT

87- 18286A19 ELECTRICAL
Rocker switch style with 25 ft.(7.62 m) harness and bullet connectors. Can be
surface mounted or flush mounted. Provides tilt control from the bow or transom
87- 18286A17 location.
Rocker switch style with 10 ft.(3.05 m) harness and 3 blade connector. Installation Fits Mercury/Mariner models equipped with integral trim pump.
requires power trim "Y" harness (58366A 2). Provides tilt control from the bow or
transom location.
Fits Mercury/Mariner models equipped with remote mounted trim pump.

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 615
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
