676 | ChapteR 15 Creating StairS and railingS

Start by creating a single panel using the Curtain Panel template. The family may contain not
only the panel for the railing but also the balusters. Once you load this panel into your project,
you can create curtain walls with predefined panel widths (Figure 15.77).

Figure 15.77
Curtain panel
railing with
custom baluster
locations

Because curtain panels allow you to unpin predefined grids (as well as create other grid
locations), you’ll be able to quickly and easily make exceptions to the rules that you previously
defined (Figure 15.78) and create several unique baluster locations specific to the installation.

Figure 15.78
adjusted baluster
locations
