The Bottom Line
Add revisions to your project. You need the ability to track changes in your design
after sheets have been issued. Adding revisions to a drawing is an inevitable part of your
workflow.
Master It How do you indicate revisions on a drawing sheet?
Use digital markups. DWFs provide a lightweight means to digitally transfer and mark up
multiple sheets in a document set.
Master It Explain the workflow using DWF markups.
Model for construction. Parts and assemblies allow a model element to be broken down
into smaller parts. These subelements can be used in more detailed ways for the construction
process while still maintaining their association with the original element.
Master It Describe the method for breaking down a design-based model assembly into
its individual components.
