Hose
A Parkrimp 2
Part No. 83C-081-PFD

Tubing
B

View video tutorial

Coiled Air Hose & Fittings

C Capability

ƒ Crimps hoses up to 2" I.D.
(reference crimp source for details)

Features
Transportation ƒ Easy to use vertical design

ƒ For use with 54, 56, 91, 91N, 92, 93N, CG, CY, MS, SF and HY Series fittings
D ƒ Crimps full range of Parker hoses from 1/8" through 2" I.D.

Specifications

ƒ Dimensions: 31" wide, 24" deep, 77" high
ƒ Weight: 842 lbs (Head is 558 lbs and base
Fittings ƒ Rating: is 284 lbs)
125 ton force @ 5,000 psi maximum
E ƒ Full Cycle Time: 30 seconds without adapter bowl

20 seconds with adapter bowl
ƒ Hydraulic oil: Enerpac oil only
Standard Equipment
Part Number Individual
83C-001-PFD 83C-081-PFD 83C-002-PFD 83C-082-PFD Description Part Number
Parkrimp 2 crimper 83C-080-PFD
Tooling, Equipment & Accessories Ä Ä Parkrimp 2 stand 83C-S40-PFD
Ä
Ä
Ä
Ä
head assembly
assembly with
230/460 volt, 3 phase,
50/60 Hz power unit
F (wired for 230 volt)
Parkrimp 2 stand
Ä Ä assembly with 230 83C-S20-PFD
volt, 1 phase, 50/60 Hz
power unit
Ä Ä Ä Ä Adapter bowl 83C-OCB-PFD
83C-R02-PFD
Spacer ring
Ä
General Technical Ä Ä Ä Ä Spacer Plate 83C-R02H-PFD
Ä
Ä
Ä
G For detailed ordering information, please consult price list or contact Parflex Division.
