Hose
A
Hand Pump Hand Pump
Part No. 82C-0HP-PFD Part No. 85C-0HP-PFD

(for use with the MiniKrimp, Karrykrimp and Karrykrimp 2)
Tubing Ease of operation hand pump delivers 10,000 psi (for use with the MiniKrimp, Karrykrimp and Karrykrimp 2)
ƒ Length:
13-3/8"
B ƒ Width: 3-1/4" Ease of operation hand pump delivers 10,000 psi
29"
ƒ Length:
ƒ Height: 3-5/8" ƒ Width: 13"
ƒ Port Size: 1/4" NPTF ƒ Height: 11"
ƒ Weight: 4.7 lbs. ƒ Port Size: 3/8" NPTF
ƒ Hydraulic Fluid: Enerpac oil only
ƒ Weight: 61 lbs
ƒ Hydraulic Fluid: Enerpac oil only
Coiled Air Hose & Fittings

C Electric Pump Electric Pump
Part No. 82C-0EP-PFD Part No. 85C-0EP-PFD

(for use with the MiniKrimp,
Karrykrimp and Karrykrimp 2)
Transportation Ease of operation electric pump (for use with the MiniKrimp, Karrykrimp and Karrykrimp 2)
delivers 10,000 psi
Heavy duty electric pump delivers 10,000 psi at a faster
D ƒ Length: 13" cycle time
ƒ Width: 13" ƒ Length: 19"
ƒ Height: 15" ƒ Width: 11"
ƒ Port Size: 3/8" NPTF ƒ Height: 17"
ƒ Weight: 31 lbs ƒ Port Size: 3/8" NPTF
ƒ Hydraulic Fluid: Enerpac oil only ƒ Weight: 59 lbs
ƒ 115 volt, 1 phase, 50/60 Hz, 9 amp ƒ Hydraulic Fluid: Enerpac oil only
ƒ 115 volt, 1 phase, 50/60 Hz, 20 amp
Fittings
E
Vise Blocks Hose Insertion Depth Blocks
For Parflex Hose Sizes Part No. TH9-1-xxx
Part No. TH8-1-xxx

Tooling, Equipment & Accessories Part Number -3 3/16 TH9-1-CG CG Series. All sizes.
Hose Size
Description
Part Number
TH9-1-56
56 Series. All sizes.
1/4
-4
-5
TH9-1-54A
54 Series All sizes.
VBS
5/16
F -6 3/8 TH9-1-91N 91N Series. All sizes.
1/2
-8
TH9-1-93N_20_32 93N Series. Sizes: -20, -24, -32
-12 3/4 TH9-1-93N_6_16 93N Series. Sizes: -6, -12, -16
VBL
-16 1 TH9-1-94_95 94 & 95 Series. All sizes.
TH9-1-CY_SF CY & SF Series. All sizes.
TH9-1-MS MS Series. All sizes.
General Technical
TH9-1-HY
HY Series. All sizes.
G For detailed ordering information, please consult price list or contact Parflex Division.
