Parflex Parkrimp Dies A Hose

Parkrimp dies, specifically engineered for thermoplastic and fluoropolymer hose:

ƒ Linked die segments ƒ Fitting size color coded
ƒ Pre-matched and assembled

Tubing
Color Code Color Code Color Code Parkrimp Approved Silver Die Rings B
Size Color Size Color Size Color Machine Approved Die
-1.5 -6 -20 Parkrimp 2 NA*
GR Y W
Karrykrimp and MiniKrimp 82C-R01-PFD
-2 -8 -24
BR BL R
Karrykrimp 2 85C-R01-PFD
-3 -10 -32
GR O G *No additional silver die rings required.
-4 -12
R G Coiled Air Hose
-5 P -16 B & Fittings

Note: 1) Parflex dies have been designed for use with the 2) For most Parker products, Crimp Die information and C
silver die ring. Silver die rings are to be used with selection charts can be found online at www.parker.
all Parflex hoses unless otherwise specified. com/crimpsource. Access instructions are on pg. G-13.

Transportation

D

Die Racks

Die Storage Rack
Part No. 80C-0DR-PFD/83C-0DR-PFD Fittings
E
ƒ Holds small and large Parkimp dies Description Part No.
ƒ Can be bolted together to a work bench
Storage 3 small dies 80C-0DR-PFD
Storage 2 large dies 83C-0DR-PFD

Swivel Die Rack Tooling, Equipment
Part No. 80C-SDR-XXXX-PFD & Accessories

ƒ Holds up to 30 Parkimp dies Description Part No. F
ƒ Powder coated, heavy duty steel construction Swivel Die Rack and Small Die Holder 80C-SDR-SM-PFD
ƒ Consist of base unit and up to 5 circular holders
ƒ Floor or bench mounted Swivel Die Rack and Large Die Holder 80C-SDR-LG-PFD
Swivel Die Rack Base 80C-SDR-BASE-PFD

General Technical

For detailed ordering information, please consult price list or contact Parflex Division. G
