6 I/O-System — SPEEDWAY
430 General Product Information

Uncompromising Protection, Even in the Hars- Ergonomic Design
For Cabinet-Free Data Acquisition
hest Environments Standardized M8, M12 and M23 connections
Where previously discrete wiring was once
required, fieldbuses now provide communi- Every module utilizes IP67-grade protection and ro- (metal design) ensure easy and safe wiring. The
cation between the control and field levels. bust construction. These fully encapsulated modules fieldbus, system bus, power supply and sensors/
actuators are connected via several coded
Depending on the application, cabinet-free safeguard system operation, even when subjected
connectors. This streamlined approach prevents
automation systems help minimize costs for to temperature extremes and prolonged periods of
planning, start-up and maintenance. vibration. When combined, these robust design ele- wiring errors.
To accommodate custom marking, the modules
ments ensure long-term electronic circuit protection.
In addition to requiring a high degree of have marking strips and a WMB plate. Both the
Additionally, moisture cannot penetrate the units to
protection, a robust design and standard- LEDs and marking field are uniquely assigned to
cause damage (e.g., hairline cracks).
ized connection technology, there is an the connection.
Electromagnetic shielding consisting of a metallized
increasing demand for advanced IP67
housing and shield plating guarantees optimal Flexible Assembly
features that were once reserved only for
IP20 systems, including: electromagnetic compatibility within the housing. The modules can be directly mounted on ma-
Potential on-machine interferences are directly chines. Extensive engineering ensures compliance
• Real-time capability for isochronous data deflected via the modules’ brackets or system’s with standardized specifications from CNOMO
guidelines regarding the spacing of assembly drill
acquisition/output mounting rail. Even in sub-zero temperatures, the
holes that are often used in passive distributor or
• Parameterizable WAGO SPEEDWAY I/O-System performs reliably.
• Diagnostic capable sensor/actuator boxes. Adapters for both rails
and machine-mount brackets are also available.
• Upgradable Modular Design
WAGO SPEEDWAY 767 is a fieldbus-
From the cabinet directly to the field independent modular IP67 I/O system. It is Exceptional Degrees of Freedom
level without sacrificing functionality — linked via a fieldbus coupler with a higher- Featuring update capability, the SPEEDWAY
SPEEDWAY for perfectly tailoring level controller. The fieldbus coupler already I/O-System makes it easy to update fieldbus
machines to meet specific, decentralized has digital inputs. An integrated system bus couplers and I/O module firmware to incorporate
needs. Configuration is both easy and interface connects to other I/O modules. new functions.
flexible, with changes being made safely Fieldbus couplers and I/O modules can be Integrated system parameter handling stores
and quickly (plug & play). extensively parameterized, allowing direct and loads parameter settings and checks that the
field-side acquisition and transmission of replacement module is correct when installed.
With option handling, variable I/O station
signals depending on the application needs.
configurations, which can occur when tools are
Up to: changed in a machining center, can be implemen-
• 64 I/O modules per station ted without engineering via PROFIBUS.
• 8 channels per module
• 520 channels per station
• 50 m between two modules
• 500 m total extension per station

● Fully encapsulated for harsh environmental conditions
● Fieldbus-independent — compatible with all standard
fieldbus protocols & ETHERNET standards
● Real-time capability up to isochronous mode for selected
ETHERNET-based fieldbuses
● Exclusive use of standard pluggable connectors
● Flexible mounting options
