6

449

System bus 1: RD+/TD+
Input Output 2: RD--/TD-- Block diagram of an input
3: TD--/RD--
4 4
1 5 3 3 5 1 4: TD+/RD+ Digital Input Supply
2 2 5: GND
Housing: Shield X1 ... X8
M12 B coded
M12
1
Diagnostics 3
M8
Digital Inputs 1: 24 V
X1 ... X8 3: 0 V U 1
LS
Logic
3 4 4 1 — +
1 3
3
M8 Input 0 ... 7
4: Input
4 Error F
270 pF 270 pF
Supply 1: 24 V U
Input Output 2: 24 V U LS
3: 0 V U A Module
2 2 LS
3 1 1 3 4: 0 V U A mount
4 4
M12 A coded

Technical Data Technical Data
Input characteristic: Isolation: 6
Input voltage Typical input current Channel – Channel No
-30 V DC < U IN < 0 V DC 0 U LS , U A , system bus 500 V DC each
5 V 2.4 mA Configurable functions:
11 V 6.4 mA Input filter (per channel) 0.1/ 0.5/ 3 /15 /20 ms/ filter off
24 V 7.3 mA Inversion (per channel) On/off
30 V 7.4 mA Online simulation (per channel) Lock/unlock, simulation value: 0/1
System bus: Online simulation (per module) Diagnostics
Connection type (3) M12 connectors, B coded, 5 poles, I/O diagnostics:
shielded I/O diagnostics (per module) Short circuit/overload of sensor supply
Standards and approvals: Undervoltage (U LS + U A )
Conformity marking 1 Process image:
Korea Certification Process data width 1-byte data + status
r UL 508 LED indicators:
SB: System bus status LED (green/red/orange)
F: Error status LED (red)
0 ... 7: Input signal status LED (yellow)
U LS + U A : Supply status LED (green)
Indicators Non-latching

General Specifications
Dimensions (mm) W x H x L 50 x 35.7 x 117
Weight 270 g
