Suction Cups for Packaging
Flat Suction Cups SPF
PA01019111_inh_EN.pdf Suction area (Ø) from 10 to 60 mm PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Round, flat suction cup for usage in cardboard box and tray Vacuum Knowledge
erectors
• Handling of cardboard and rigid packaging in top-loading and
side-loading machines Suction Cups
Vacuum
• Palletizing and depalletizing processes
• Heavy-duty applications that require suction cups with excellent
sealing and low wear
Special Grippers

Vacuum Grip- ping Systems
Flat suction cups SPF
container
Design

• Round flat suction cup SPF (2) with soft, flexible sealing lip and
supporting studs on the suction surface Mounting Elements
• Made of wear-proof material Elastodur ED-65
• Models with diameter up to 30 mm feature plug-in connection
element for quick change of suction cup
• Starting at 40 mm diameter with a 2-piece connection element: Vacuum Generators
consisting of machine-side component (1) and suction-side
component (3)
• Clip-in filter screen (4) as pre-filter (filter pore size 250 µm) Technology
• All connection elements with male thread are equipped with Valve
System design flat suction cups SPF integrated sealing
Switches and Monitoring
container
Our Highlights... Your Benefits...
• Flexible, adaptable sealing lip >Excellent sealing when used
on cardboard and rigid
packaging Filters and Connections
• Robust, reinforced main body >High intrinsic stability of the
suction cup
• Supporting studs on the >Maximum effective diameter
suction surface for high suction force
• Wear-proof and abrasion- >Very low wear, approx. 3 Services
proof material Elastodur times higher compared to
ED-65 NBR
Contact
Flat suction cups SPF being used in packaging machines

Index of Products

container
www.schmalz.com/spf
