Suction Cups for Packaging
Bellows Suction Cups SPB2 (2.5 Folds)
PA01019111_inh_EN.pdf Suction area (Ø) from 20 mm to 50 mm PA01019111_inh_EN.pdf

container
Designation Code Bellows Suction Cups SPB2 (2.5 Folds)
Schmalz - The Company container Abbreviated designation Suction area Ø Material and Connection thread

Example SPB2 30 ED-65 G1/8-AG: in mm Shore hardness G1/8-AG
SPB2
30
ED-65
Vacuum Knowledge SPB2 20 ED-65 G1/4-AG (AG = male (M))
G1/4-IG
to
(IG = female (F))
50 G1/8-AG
G1/8-IG
Vacuum Suction Cups container Ordering Data Bellows Suction Cups SPB2 (2.5 Folds)

Suction cup SPB2 (elastomer part + connection element) is delivered assembled. As an alternative the individual parts can also be ordered
container
separately. To do this, the following ordering steps are required:
Special Grippers • Suction cup of type SPB2 (step 1) - elastomer part, available in various diameters
• Connection element of type SC (step 2) - available with various threads
Vacuum Grip- ping Systems container Bellows Suction Cups SPB2 (2.5 Folds) (Mounted)

container
Type Connection
G1/4"-M G1/4"-F G1/8"-M G1/8"-F
Mounting Elements SPB2 20 ED-65 - - - - - - 10.01.06.03453 10.01.06.03454
SPB2 25 ED-65
10.01.06.03456
10.01.06.03455
10.01.06.03457
SPB2 30 ED-65
10.01.06.03458
SPB2 40 ED-65 10.01.06.03459 10.01.06.03460 - -
SPB2 50 ED-65 10.01.06.03461 10.01.06.03462 - -
Vacuum Generators container Step 1: Bellows Suction Cups SPB2 (2.5 Folds) (Single Component)
container Type Part Number
Valve Technology SPB2 20 ED-65 SC040 10.01.06.03409
10.01.06.03410
SPB2 25 ED-65 SC040
SPB2 30 ED-65 SC040 10.01.06.03411
Switches and Monitoring SPB2 50 ED-65 SC050 10.01.06.03413
SPB2 40 ED-65 SC050
10.01.06.03412
container
Step 2: Connection Elements Bellows Suction Cups SPB2 (2.5 Folds)
Filters and Connections container Type SPB2 20 SPB2 25 SPB2 30 SPB2 40 SPB2 50

-
-
10.01.06.02490
10.01.06.02490
SC 040 G1/8-AG
10.01.06.02490
SC 040 G1/8-IG 10.01.06.02482 10.01.06.02482 10.01.06.02482 - -
SC 050 G1/4-AG - - - 10.01.06.02487 10.01.06.02487
SC 050 G1/4-IG - - - 10.01.06.02488 10.01.06.02488
Services
Contact

Index of Products

210 www.schmalz.com/spb2
