Suction Cups for Packaging
Bellows Suction Cups SPOB1f (Oval, 1.5 Folds)
PA01019111_inh_EN.pdf Suction area (LxW) from 35x15 mm to 80x35 mm PA01019111_inh_EN.pdf

container
Suitable for Industry Specific Applications
Schmalz - The Company

container
Applications
• Oval bellows suction cup with 1.5 folds for reliable handling of Vacuum Knowledge
small, film packaging products such as candy bars, popsicles or
bulk materials
• Used in packaging lines for processing bulk material packaging in
the case-packing process step Vacuum Suction Cups
• Handling of small flow-wrap packaging with different fill levels

• Stability and high suction force in rapid packaging processes
thanks to its oval shape
Special Grippers

Vacuum Grip- ping Systems
Bellows suction cups SPOB1f (oval, 1.5 folds)
container
Design

• Oval bellows suction cup with 1.5 folds (3) with a very soft and
flexible sealing lip Mounting Elements
• Integrated anti-rotation guard and easy-to-use function for
positioning the suction cup on the workpiece (2)
• Large shaft diameter for high flow rates
• Mounting using one-piece Schmalz SC 040 connection element Vacuum Generators
(1) respectively two-piece Schmalz SC 050 connection element (1)
and (4)
• All SC connection elements with male threads come equipped Technology
with an integrated sealing ring Valve
System design bellows suction cups SPOB1f (oval, 1.5 folds)
Switches and
container
Our Highlights... Your Benefits... Monitoring
• Oval shape with 1.5 folds >High holding force and
secure gripping even on small
workpieces such as tubular
bag packaging Filters and Connections
• Very flexible and easy-to- >Optimum sealing for bag
adapt sealing lip and suction packaging even when the
bellows bags have an extremely large
number of folds and are not Services
very full
• Integrated anti-rotation guard >Simple and reliable position-
ing of the suction cup on the
workpiece (no additional
SPOB1f bellows suction cups for handling small flow-wrap packaging component parts required) Contact
• Large nominal diameter >High flow rates for short cycle
times
• FDA-compliant silicone >Capable of direct use in the Index of Products
material food product sector
container
container 225
www.schmalz.com/spob1f
