Suction Cups for Packaging
Bellows Suction Cups SPB2f (2.5 Folds)
PA01019111_inh_EN.pdf Suction area (Ø) from 30 mm to 50 mm PA01019111_inh_EN.pdf

container
Designation Code Bellows Suction Cups SPB2f (2.5 Folds)
Schmalz - The Company container Abbreviated designation Suction area Ø Material and Connection thread

Example SPB2f 30 SI-55 G1/8-AG: in mm Shore hardness G1/8-AG
SPB2f
30
SI-55
Vacuum Knowledge SPB2f 30 SI-55 G1/8-AG (AG = male (M))
G1/8-IG (IG = female (F))
to
50 G1/4-AG
G1/4-IG
Vacuum Suction Cups G3/8-AG
G3/8-IG

container
Ordering Data Bellows Suction Cups SPB2f (2.5 Folds)
Special Grippers Suction cup SPB2f (elastomer part + connection element) is delivered assembled. As an alternative the individual parts can also be ordered
container
separately. To do this, the following ordering steps are required:
• Suction cup of type SPB2f (step 1) - elastomer part, available in various diameters
Vacuum Grip- ping Systems container Bellows Suction Cups SPB2f (2.5 Folds) (Mounted)
• Connection element of type SC (step 2) - available with various threads

container Type Part Number
Mounting Elements SPB2f 30 SI-55 G1/8-AG 10.01.06.03698
SPB2f 30 SI-55 G1/8-IG
10.01.06.03699
SPB2f 30 SI-55 G1/4-AG 10.01.06.03700
SPB2f 30 SI-55 G1/4-IG 10.01.06.03701
Vacuum Generators SPB2f 30 SI-55 G3/8-AG 10.01.06.03702
10.01.06.03703
SPB2f 30 SI-55 G3/8-IG
SPB2f 40 SI-55 G1/8-AG 10.01.06.03646
SPB2f 40 SI-55 G1/8-IG 10.01.06.03647
10.01.06.03648
SPB2f 40 SI-55 G1/4-AG
Valve Technology SPB2f 40 SI-55 G1/4-IG 10.01.06.03649
SPB2f 40 SI-55 G3/8-AG
10.01.06.03650
SPB2f 40 SI-55 G3/8-IG 10.01.06.03651
Switches and Monitoring SPB2f 50 SI-55 G1/8-IG 10.01.06.03653
10.01.06.03652
SPB2f 50 SI-55 G1/8-AG
SPB2f 50 SI-55 G1/4-AG
10.01.06.03654
SPB2f 50 SI-55 G1/4-IG
10.01.06.03656
SPB2f 50 SI-55 G3/8-AG 10.01.06.03655
SPB2f 50 SI-55 G3/8-IG
10.01.06.03657
Filters and Connections SPB2f 50 SI-55 G1/2-AG 10.01.06.03658
SPB2f 50 SI-55 G1/2-IG
10.01.06.03659
container
Step 1: Bellows Suction Cups SPB2f (2.5 Folds) (Single Component)
Services container Type Part Number
SPB2f 30 SI-55 SC080 10.01.06.03643
SPB2f 40 SI-55 SC080 10.01.06.03559
Contact SPB2f 50 SI-55 SC090 10.01.06.03560

Index of Products

230 www.schmalz.com/spb2f
