Suction Cups for Plastic Films and Paper
Flat Suction Cups SGPN
PA01019111_inh_EN.pdf Suction area (Ø) from 15 mm to 40 mm PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Round, flat suction cup for handling of wooden veneers, wafers
and solar cells
• Handling of various packing material, e.g. plastic films, paper,
blister packs
Vacuum Suction Cups • Gentle handling of plastic films and paper due to flat, long-
tapered sealing lip and inner support

Special Grippers

Vacuum Grip- ping Systems Flat suction cups SGPN Design

container

• Robust, wear-resistant suction cup SGPN (3) with single sealing
Mounting Elements • Nipple plugged into cup
lip, consisting of suction cup SGP (2) and connection nipple (1)

• With each nipple family, the replacement cups and nipples can be
combined as desired
Vacuum Generators

Valve Technology

System design flat suction cups SGPN
Switches and Monitoring container Our Highlights... Your Benefits...

• Flat, long-tapered sealing lip >No "pulling-in" into the
and inner support
suction cup, i.e. very suitable
Filters and Connections for plastic film, paper and
solar cells
• Material: natural rubber NK >No crinkling when gripping
40 Shore A paper and plastic film

Services • Material: Silicone SI 50 >Resistant to ozone, UV
Shore A
radiation and heat; very
suitable for handling tasks
in the paper and printing
industry
Contact Flat suction cups SGPN being used for handling blister packagings • Material: HT1 >No marks on the workpiece;
even at high temperatures

Index of Products

256 www.schmalz.com/sgpn
