Check Valves and Flow Restrictors
Check Valves SVK, SVKG, SVV
PA01019111_inh_EN.pdf Connection thread from M5 to G1/2" PA01019111_inh_EN.pdf

container
Schmalz - The Company container Design Data Check Valves SVK, SVKG, SVV

Vacuum Knowledge

Vacuum Suction Cups

Special Grippers SVK M5 to G1/2 SVKG M5 to G1/2

Vacuum Grip- ping Systems container

Mounting Elements

Vacuum Generators

Valve Technology SVV G1/4
container
Type Dimensions in mm G1 G2 L LG1 LG2 SW1
Switches and Monitoring SVK M5-IG - - G1/8"-M G1/8"-F 15.5 4.5 4.5 14 8
B
M5-M
M5-F
SVK G1/8-IG
8.0
8.5
26.0
SVK G1/4-IG
22
29.0
G3/8"-M
12.0
SVK G3/8-IG - - - G1/4"-M G1/4"-F 26.0 10.0 11.0 17
G3/8"-F
10.0
14.0
G1/2"-F
12.0
29.0
27
SVK G1/2-IG
G1/2"-M
Filters and Connections SVKG M5-AG - - G1/8"-F G1/8"-M 20.0 4.5 4.5 14 8
M5-F
M5-M
8.5
8.0
26.0
SVKG G1/8-AG
SVKG G1/4-AG - G1/4"-F G1/4"-M 26.0 11.0 10.0 17
SVKG G3/8-AG - G3/8"-F G3/8"-M 29.0 12.0 10.0 22
SVKG G1/2-AG - G1/2"-F G1/2"-M 29.0 14.0 12.0 27
Services SVV G1/4-IG 23.9 G1/4"-M G1/4"-F 42.5 8.0 11.0 17
