Pack.
Description Item No.
Unit
WAGO Interface Cable A8E, 1 m long 706-2300/400-100 1
WAGO Interface Cable A8E, 2 m long 706-2300/400-200 1
WAGO Interface Cable A8E, 3 m long 706-2300/400-300 1
7
Technical Data
Ports 1 x Siemens 6ES7-392-1BJ00-0AA0
1 x 25-pole D-sub female connector
2
Wire cross-section 0.25 mm Li YCY
Color coding acc. to DIN VDE 47100
Operating voltage 125 V
Current per channel max. 2 A
Operating temperature -20 °C … +50 °C
Degree of protection IP20
Length 1 m (706-2300/400-100)
2 m (706-2300/400-200)
3 m (706-2300/400-300)
