WINSTA MIDI special 4
®
Cable Assemblies 3 x 1.5 mm²
175
PVC Control line: 3 x 1.5, gray

250 V/4 kV/3 I 16 A
N
Conductor ends, bonded: 9 mm
1 Approvals
Interconnecting cable, socket – plug Length Item No. Item No. Item No.
Coding B
PVC
1 m 771-9993/006-103 771-9993/006-105 771-9993/006-107
2 m 771-9993/006-203 771-9993/006-205 771-9993/006-207
3 m 771-9993/006-303 771-9993/006-305 771-9993/006-307
4 m 771-9993/006-403 771-9993/006-405 771-9993/006-407
5 m 771-9993/006-503 771-9993/006-505 771-9993/006-507
<_______69________> <_______69________> 6 m 771-9993/006-603 771-9993/006-605 771-9993/006-607
<_27_> <_27_> 7 m 771-9993/006-703 771-9993/006-705 771-9993/006-707 4
771-9993/006-805
771-9993/006-803
771-9993/006-807
8 m
<____________________________________ L ____________________________________>
Connecting cable, socket – free end Length Item No. Item No. Item No.
Coding B
PVC
3
2 1 m 771-9993/106-103 771-9993/106-105 771-9993/106-107
1 2 m 771-9993/106-203 771-9993/106-205 771-9993/106-207
3 m 771-9993/106-303 771-9993/106-305 771-9993/106-307
4 m 771-9993/106-403 771-9993/106-405 771-9993/106-407
5 m 771-9993/106-503 771-9993/106-505 771-9993/106-507
<_______69________> <_______55_______> 6 m 771-9993/106-603 771-9993/106-605 771-9993/106-607
> 9 < 7 m 771-9993/106-703 771-9993/106-705 771-9993/106-707
<_27_> 8 m 771-9993/106-803 771-9993/106-805 771-9993/106-807

<_____________________________________ L _____________________________________>
Connecting cable, plug – free end Length Item No. Item No. Item No.
Coding B
PVC
1
2 1 m 771-9993/206-103 771-9993/206-105 771-9993/206-107
3 2 m 771-9993/206-203 771-9993/206-205 771-9993/206-207
3 m 771-9993/206-303 771-9993/206-305 771-9993/206-307
4 m 771-9993/206-403 771-9993/206-405 771-9993/206-407
5 m 771-9993/206-503 771-9993/206-505 771-9993/206-507
<_______69________> <_______55_______> 6 m 771-9993/206-603 771-9993/206-605 771-9993/206-607
> 9 < 7 m 771-9993/206-703 771-9993/206-705 771-9993/206-707
<_27_> 8 m 771-9993/206-803 771-9993/206-805 771-9993/206-807

<____________________________________ L _____________________________________>
Item numbers overview for other cable lengths

Position 1 – 3 - 4 5 6 7 / 8 9 10 - 11 12 13

gray 771 - 9 9 9 3 / 0 0 6 - 1 0 3
light green 771 - 9 9 9 3 / 0 0 6 - 1 0 5
pink 771 - 9 9 9 3 / 0 0 6 - 1 0 7
The item numbers listed above correspond to the following cable version:
Interconnecting cable, 3-pole, socket – plug, PVC control line, 3 x 1.5 mm , 1 m long
2
The 9th position defines whether it is a PVC or halogen-free cable. For example, an halogen-free cable with pink connectors has the following item number: 771-9993/016-107.
The 10th position defines the cable cross-section. For example, a 3 x 1 mm cable with light green connectors has the following item number: 771-9993/005-105.
2
The 11th position defines the cable length. For example, a 5-meter cable with gray connectors has the following item number: 771-9993/006-503.
WINSTA — perfectly plugged!
®
