$ 8

219
PVC J-Y(ST)Y...LG 1x2x0.8

50 V/0.8 kV/3 I 3 A
N
1 Approvals

Interconnecting cable, socket – plug Length Item No.

Coding F, 2
for standard fieldbus applications
halogen-free
1 m 894-8992/023-107

3 m 894-8992/023-307

< <______ 47,5 ______> <______ 47,5 ______> < 5 m 894-8992/023-507
14,1 14,1
> <____________________________________ L _____________________________________> >

Connecting cable, socket – free end Length Item No.

Coding F, 2
for standard fieldbus applications
1+ halogen-free
2–
1 m 894-8992/123-107
3 m 894-8992/133-307
<____23____> 5 m 894-8992/123-507
< <______ 47,5 ______> > 9 <
14,1
> <____________________________________ L _____________________________________>

Connecting cable, plug – free end Length Item No.
Coding F, 2 8
for standard fieldbus applications
halogen-free
2–
1+
1 m 894-8992/223-107
3 m 894-8992/223-307
<____23____> 5 m 894-8992/223-507
< <______ 47,5 ______> > 9 <
14,1
> <____________________________________ L _____________________________________>

WINSTA — perfectly plugged!
®
