Parker Pneumatic Parker Global Air Preparation System

Regulator Dimensions - mm (inches)

P31 P32

94
64 65 (3.74)
40 37 (2.53) (2.57)
(1.58) (1.46)
34.1 78.7
(1.34)
61 (3.1)
(2.4)
100.1 136
(3.94) (5.4)
93
(3.66)

30 60
(1.2) (2.36)
60
(2.36)

NOTE: Ø 30 mm hole required for panel nut mounting. NOTE: Ø 47 mm hole required for panel nut mounting.

P33

108
(4.27)
72
(2.83)

83.8
(3.3)
149
(5.9)
105
(4.16)

37 73
(1.44) (2.9)
73
(2.9)

NOTE: Ø 60 mm hole required for panel nut mounting.
