Parker Pneumatic Parker Global Air Preparation System
Filter Regulator Dimensions - mm (inches)
P31 P32
60
(2.36)
64 30 60
(2.53) (1.2) (2.36)
37 40
(1.46) (1.58)
93
(3.66)
66
(2.6)
248
164.1 (9.76)
(6.46)
Use 10mm
or 3/8” Flex
7mm (0.275”) 4mm (5/32”) 4.8 (0.19) Bowl Tubing
I.D. Tube fitting I.D. Tube fitting 33.3 Bowl I.D. Tube removal
(1.31) removal Barb fitting clearance 65
clearance 41 (2.57)
(1.6) 95
Note: (3.74)
Flush-mounted gauge kits will not fit units originally purchased with
threaded gauge ports. Manual Drain Automatic Drain
P33
73
(2.9)
37 73
(1.44) (2.9)
104
(4.1)
291
(11.44)
Use 10mm
or 3/8” Flex
4.8 (0.19) Tubing
I.D. Tube 51 Bowl
Barb fitting (2.0) removal
clearance 72
(2.83)
108
(4.27)
Manual Drain Automatic Drain
