Parker Pneumatic Rectus

Rectus Series 17KA - DN 5.0 Advantages

English profile industrial coupling. Specially suited to • Single handed operation
compressed air applications. Brass/steel design • Small dimensions, light weight
developed for industry. Schrader (DN 5.0) Interchange. • UltraFlo technology with high flow valve

Chart / Air

Pressure Drop (bar)

Flow Rate in l/min

Working Pressure Material
PB = 35 bar, maximum static working pressure Coupling
with safety factor of 4 to1.
Back Body Brass, Nickel Plated
Valve Body Steel Hardened, Zinc Pl.
Working Temperature* Sleeve Steel Hardened, Nickel Pl.
-20°C up to +100°C (NBR) Valve Brass
depending on the medium. Inner Sleeve Brass
*At a temperature below -20°C and above +100°C Spring Plate Brass
special seals are available on request. Spring and Locking Ring AISI 303
Locking Balls AISI 420
Seals NBR
Plug Steel Hardened, Nickel Pl.

Coupling - Male Thread BSPT Plug - Male Thread BSPT

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 17KAAK13SPN 10 1/8” 17SFAK10SXN 20
3/8” 17KAAK17SPN 10 1/4” 17SFAK13SXN 20
1/2” 17KAAK21SPN 10

Coupling - Female Thread BSPP Plug - Female Thread BSPP

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 17KAIW13SPN 10 1/8” 17SFIW10SXN 20
1/2” 17KAIW21SPN 10 1/4” 17SFIW13SXN 20

Coupling - Hose Barb Plug - Hose Barb

Thread Order code Box Qty Thread Order code Box Qty
A A
8 mm 17KATF08SPN 10 8 mm 17SFTF08SXN 20
10 mm 17KATF10SPN 10 10 mm 17SFTF10SXN 20
