PDE2600PNUK
Parker Pneumatic Rectus

Rectus Series 19KA - DN 5.5 Advantages

English industrial profile with UltraFlo technology. • Single handed operation
Compact dimensions. Robust coupling for compressed • Plug design optimised through greater insert depth
air applications. The steel sleeve counters oscillating • UltraFlo technology with high flow valve
forces.

Chart / Air

Pressure Drop (bar)

Flow Rate in l/min

Working Pressure Material
PB = 35 bar, maximum static working pressure Coupling
with safety factor of 4 to1.
Back Body Brass, Nickel Plated
Valve Body Brass, Nickel Plated
Working Temperature* Sleeve Steel Hardened, Nickel Pl.
-20°C up to +100°C (NBR) Valve Zinc Diecasting, Nickel Pl.
depending on the medium. Inner Sleeve Brass
*At a temperature below -20°C and above +100°C Spring Plate Brass
special seals are available on request. Spring / Locking Ring AISI 301
Locking Balls AISI 420
Seals NBR
Plug Steel Hardened, Nickel Pl.

Coupling - Male Thread BSPT Plug - Male Thread BSPT

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 19KAAK13MPN 10 1/4” 19SFAK13SXN 20
3/8” 19KAAK17MPN 10 3/8” 19SFAK17SXN 20
1/2” 19KAAK21MPN 10

Coupling - Female Thread BSPP Plug - Female Thread BSPP

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 19KAIW13MPN 10 1/4” 19SFIW13SXN 20
1/2” 19KAIW21MPN 10 3/8” 19SFIW17SXN 20

Coupling - Hose Barb Plug - Hose Barb

Thread Order code Box Qty Thread Order code Box Qty
A A
8 mm 19KATF08MPN 10 6 mm 19SFTF06SXN 20
10 mm 19KATF10MPN 10 8 mm 19SFTF08SXN 20
10 mm 19SFTF10SXN 20

Parker Hannifin Corporation
Pneumatic Division - Europe
776
