PDE2600PNUK
Parker Pneumatic Rectus

Rectus Series 18KA - DN 5.5 Advantages

ISO 6150 C industrial coupling with UltraFlo technolo- • Single handed operation
gy. Robust design. The steel sleeve counters oscillating • Plug design optimised through greater insert depth
forces. System has limited use for liquids (steel sleeve/ • Innovative valve technology with high flow valve
zinc die cast valve).

Chart / Air

Pressure Drop (bar)

Flow Rate in l/min

Working Pressure Material
PB = 35 bar, maximum static working pressure Coupling
with safety factor of 4 to1.
Back Body Brass, Nickel Plated
Valve Body Brass, Nickel Plated
Working Temperature* Sleeve Steel Hardened, Nickel Pl.
-20°C up to +100°C (NBR) Valve Zinc Diecasting, Nickel Pl.
depending on the medium. Inner Sleeve Brass
*At a temperature below -20°C and above +100°C Spring Plate Brass
special seals are available on request. Spring / Locking Ring AISI 301
Locking Balls AISI 420
Seals NBR
Plug Steel Hardened, Nickel Pl.

Coupling - Male Thread BSPT Plug - Male Thread BSPT

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 18KAAK13MPN 5 1/4” 18SFAK13SXN 20
3/8” 18KAAK17MPN 5 3/8” 18SFAK17SXN 5

Coupling - Female Thread BSPP Plug - Female Thread BSPP

Thread Order code Box Qty Thread Order code Box Qty
A A
1/4” 18KAIW13MPN 5 1/4” 18SFIW13SXN 20
3/8” 18KAIW17MPN 5 3/8” 18SFIW17SXN 20
1/2” 18KAIW21MPN 5

Coupling - Hose Barb Plug - Hose Barb

Thread Order code Box Qty Thread Order code Box Qty
A A
8 mm 18KATF08MPN 5 6 mm 18SFTF06SXN 20
10 mm 18KATF10MPN 5 8 mm 18SFTF08SXN 20
10 mm 18SFTF10SXN 20

Parker Hannifin Corporation
Pneumatic Division - Europe
775
