Female Connectors
MCS MIDI 5
339

With fixing flanges,
With locking levers
Pin spacing: 7.5 mm / 0.295 in. Pin spacing: 7.5 mm / 0.295 in. for racks and through-panel mounting
Pin spacing: 7.5 mm / 0.295 in.
0.08–2.5 mm 2 28–12 AWG 0.08–2.5 mm 2 28–12 AWG 0.08–2.5 mm 2 28–12 AWG
630 V/ 6kV/2 16 A 300 V/15 A 630 V/ 6kV/2 16 A 300 V/15 A 630 V/ 6kV/2 16 A 300 V/15 A

<____26,45____> 2,2 > 6 < <____L____>
2,6
<_14,3_> __> < 2,6 < ___ < < <__ __> <__26,45 __> > 6 ( 14,3 _ ) _ 5
3,55 ___>
>
<____ L 1 ____>
<
3,4
<
<______ L 2 ______>
< <___ 29,6 ___> <________ L 3 ________>
> 7,5
5
<
3,4
5 2,6 <__ ( ( <__
7,5 > 8,6 < > 7,5 5 8 < > 12,2 < (_ 14,6 _) >
> <_______L ______> <___ L __> 14,3 ) > > 7,0
1,5 <__ 8,2 > 4,7 2,6 <__ > 5,1 < <
<____ L 1 ____>
> > > <______ L 2 _____ _>
<________ L 3 ________>
L = (pole no. – 1) x pin spacing + 5 mm +1.5 mm L = (pole no. – 1) x pin spacing + 5 mm L = (pole no. – 1) x pin spacing + 5 mm
L = L + 3 mm
1
L = L + 8.8 mm
2
L = L + 14.8 mm
3
Pole No. Item No. Pack. Unit Pole No. Item No. Pack. Unit Pole No. Item No. Pack. Unit
Female connector, Female connector with locking levers, Female connector with fixing flanges,
light gray light gray for racks and through-panel mounting,
with reinforcing strips, light gray
2 721-202/026-000 100 2 721-202/037-000 50 2 721-202/031-000 50
3 721-203/026-000 100 3 721-203/037-000 50 3 721-203/031-000 50
4 721-204/026-000 50 4 721-204/037-000 50 4 721-204/031-000 50
5 721-205/026-000 50 5 721-205/037-000 50 5 721-205/031-000 50
6 721-206/026-000 50 6 721-206/037-000 25 6 721-206/027-000 25
7 721-207/026-000 50 7 721-207/037-000 25 7 721-207/027-000 25
8 721-208/026-000 25 8 721-208/037-000 25 8 721-208/027-000 25
9 721-209/026-000 25 9 721-209/037-000 25 9 721-209/027-000 25
10 721-210/026-000 25 10 721-210/037-000 25 10 721-210/027-000 25
11 721-211/026-000 25 11 721-211/037-000 10 11 721-211/027-000 10
12 721-212/026-000 25 12 721-212/037-000 10 12 721-212/027-000 10

Item no. for 2- to 5-pole female connectors are identical
to item nos. for panel-mount female connectors.

For cutout dimensions, see page 488, Table 1.
2-pole female connectors - one latch only

For other lengths, please contact factory.
