2-Conductor Female Connectors
MCS MIDI 5
349

With locking levers
Pin spacing: 7.5 mm / 0.295 in. Pin spacing: 7.5 mm / 0.295 in. Handling

0.2–2.5 mm 2 24–12 AWG 0.2–2.5 mm 2 24–12 AWG
630 V/6 kV/2 16 A 300 V/20 A 630 V/6 kV/2 16 A 300 V/20 A

<___ 26,45___>
< Female connectors equipped with two CAGE CLAMP S
®
10 ,6 connections per pole allow conductors to be looped from
> <__20,8__> one connector to another without interruption. 5

Therefore, disconnecting one connector will not affect other
4,75 <___ <____ 29,8 ____> <___ 26,45___> < 2,85 ____ connectors in the circuit.
These female connectors can be mated with male headers
or CAGE CLAMP -equipped male connectors, which are
®
7,5• 7,75 < > 7,5• <___ <__20,8__> < 100 % protected against mismating.
4,75
___>
> <_______ L _______> _ <________L _______>
< 8,55 > 8 <
7,75 ___>

L = (pole no. – 2) x pin spacing + 12.5 mm

Pole No. Item No. Pack. Unit Pole No. Item No. Pack. Unit
2-conductor female connector, 2-conductor female connector with locking levers,
light gray light gray
Operating CAGE CLAMP S is easy, fast and identical to
®
2 721-2202/026-000 100 2 721-2202/037-000 50 that of CAGE CLAMP .
®
3 721-2203/026-000 100 3 721-2203/037-000 50 The screwdriver is fully inserted into the operating slot,
®
4 721-2204/026-000 50 4 721-2204/037-000 50 holding the CAGE CLAMP S open. After the conductor
has been inserted into the clamping unit and the
5 721-2205/026-000 50 5 721-2205/037-000 50 screwdriver been withdrawn, the conductor is clamped
6 721-2206/026-000 50 6 721-2206/037-000 25 safely.
2
7 721-2207/026-000 50 7 721-2207/037-000 25 Solid and fine-stranded conductors < 0.5 mm are
8 721-2208/026-000 25 8 721-2208/037-000 25 terminated and removed using a screwdriver.
9 721-2209/026-000 25 9 721-2209/037-000 25
10 721-2210/026-000 25 10 721-2210/037-000 25
11 721-2211/026-000 25 11 721-2211/037-000 10
12 721-2212/026-000 25 12 721-2212/037-000 10
2-pole female connectors - one latch only

2
Solid conductors ≥ 0.5 mm and ferruled, fine-stranded
conductors can be terminated by simply pushing them in.
Touch contacting is possible by inserting test probes into
the test slots.

For other lengths, please contact factory.
