60 Inverter System & Power Supply Unit

Overload according to output frequency (Asynchronous motor control)
• Sizes ≤ 61320
Overload HD
200
190
180
ADV200-6 • 690V power supply
ADV200 - 4 • Basic
170
160 k3
150
I out [%] 140 k1
130
120
110 k2
100
90
80
70
0 1 2 3 4 5 6 7 8 9 10
f [Hz]
_ _ Islow, .... Ifast; __ In
• Sizes ≥ 71600
Overload HD Overload LD
200 120
190 k2
180
170 110 k1
160 k3 100
150
I out [%] 140 k1 k2 I out [%] 90
130
120
110
100 80
90
80
70 70
0 1 2 3 4 5 6 7 8 9 10 0 1 2 3 4 5 6 7 8 9 10
f [Hz] f [Hz]
_ _ Islow, .... Ifast; __ In _ _ Islow, .... Ifast; __ In

Asynchronous motor control
Switching frequency
Overload Overload according to
(For Synchronous motors) “Fixed frequency” mode output frequency
Sizes (PAR 568 Switch freq. mode =0, default)
ADV200-6 Maximum
Heavy Duty Light Duty Minimum Heavy Duty Light Duty
(default)
K1 HD K2 HD K3 HD K1 LD K2 LD
[a] [a] (KHz) (KHz)
[%] [Hz] [Hz] [%] [Hz]
5750 4 2 100 3 5 100 3
6900 150% 60 sec. 4 2 100 3 5 100 3
every 300 sec., n.a.
61100 200% 3 sec. 2 2 100 3 5 100 3
61320 2 2 100 3 5 100 3
71600 4 2 100 3 5 100 3
72000 2 2 100 3 5 100 3
72500 2 2 100 3 5 100 3
73150 2 2 100 3 5 100 3
73550 2 2 100 3 5 100 3
400 kW 160% 60 sec. every 2 2 100 3 5 100 3
500 kW 300 sec., 110% 60 sec. 2 2 100 3 5 100 3
630 kW 200% 3 sec. 2 2 100 3 5 100 3
710 kW 2 2 100 3 5 100 3
900 kW 2 2 100 3 5 100 3
1 MW 2 2 100 3 5 100 3
1.35 MW 2 2 100 3 5 100 3
1.65 MW 2 2 100 3 5 100 3
