Page 67 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

L
L L

H1
H
F
H2
172PLM Male Branch Tee
F K
171PLM Male Run Tee Inch Tube to NPT to tube
Metric Tube To Tube to BSPT ØK PART NO. SIZE IN NPT/UNF MM H IN K IN L Prestolok PLM Metal Push-to-Connect Fittings
F
TUBE
IN
TUBE F H1 H2 K L 172PLM-5/32-0 5/32 10-32 10.00 1.00 .47 .71
PART NO. SIZE BSPT MM MM MM MM MM
MM 172PLM-5/32-2 5/32 1/8 11 .87 .47 .71
171PLM-4M-2R 4 1/8 10 18.00 19.50 11.00 23.00 172PLM-5/32-4 5/32 1/4 14 1.04 .59 .71
171PLM-6M-2R 6 1/8 13 21.50 23.50 14.00 28.00 172PLM-4-2 1/4 1/8 13 1.18 .55 .87
171PLM-6M-4R 6 1/4 14 21.50 24.50 15.00 28.00 172PLM-4-4 1/4 1/4 14 1.22 .59 .87
171PLM-8M-2R 8 1/8 14 23.50 25.00 15.00 31.00 172PLM-4-6 1/4 3/8 18 1.22 .77 .87
171PLM-8M-4R 8 1/4 14 23.50 26.50 15.00 31.00 172PLM-6-4 3/8 1/4 18 1.54 .77 1.14
171PLM-10M-4R 10 1/4 18 29.00 30.50 19.50 37.50 172PLM-6-6 3/8 3/8 18 1.61 .77 1.14
171PLM-10M-6R 10 3/8 18 29.00 32.50 19.50 37.50 172PLM-6-8 3/8 1/2 22 1.61 .94 1.14
171PLM-12M-6R 12 3/8 21 31.00 36.50 23.00 40.50 172PLM-8-6 1/2 3/8 22 1.85 .94 1.22
171PLM-14M-8R 14 1/2 22 34.00 40.00 24.00 45.00 172PLM-8-8 1/2 1/2 22 1.89 .94 1.22

L

H 1 L L

H 2 H
F
F
K
171PLM Male Run Tee K
Tube To Tube to BSPP or M5 172PLM Male Branch Tee
TUBE BSPP/ F H1 H2 K L Metric Tube to BSPT
PART NO. SIZE M5 MM MM MM MM MM
MM PART NO. TUBE BSPT F H K L
SIZE MM MM MM MM MM
171PLM-4M-M5 4 M5X0.8 10 18.00 22.50 11.00 23.00
172PLM-4M-2R 4 1/8 10 24.50 11.00 18.00
171PLM-4M-2G 4 1/8 13 18.00 20.50 14.00 23.00
172PLM-6M-2R 6 1/8 13 29.50 14.00 21.50
171PLM-6M-2G 6 1/8 13 21.50 25.00 14.00 28.00
172PLM-6M-4R 6 1/4 14 30.50 15.00 21.50
171PLM-6M-4G 6 1/4 16 21.50 24.50 17.50 28.00
172PLM-8M-2R 8 1/8 14 32.50 15.00 23.50
171PLM-8M-2G 8 1/8 14 23.50 26.50 15.00 31.00
172PLM-8M-4R 8 1/4 14 34.00 15.00 23.50
171PLM-8M-4G 8 1/4 16 23.50 26.50 17.50 31.00
172PLM-10M-4R 10 1/4 18 39.00 19.50 29.00
171PLM-10M-4G 10 1/4 18 29.00 33.00 19.50 37.50
172PLM-10M-6R 10 3/8 18 41.00 19.50 29.00
171PLM-12M-6G 12 3/8 21 31.00 36.50 23.00 40.50
172PLM-12M-6R 12 3/8 21 46.50 23.00 31.00
171PLM-14M-8G 14 1/2 24 34.00 38.50 26.00 45.00
172PLM-14M-8R 14 1/2 22 50.50 24.00 34.00

Parker Hannifin Corporation | Fluid System Connectors | Otsego, MI A41
